Model Name: ASROCK H310CM-DVS

Specification

• Unique Feature
• ASRock Super Alloy
• Sapphire Black PCB
• High Density Glass Fabric PCB
• ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
• ASRock Live Update & APP Shop
• CPU
• Supports 9th and 8th Gen Intel® Core™ Processors (Socket 1151)
• Supports CPU up to 95W
• 4 Power Phase design
• Supports Intel® Turbo Boost 2.0 Technology
• Chipset
• Intel® H310
• Memory
• Dual Channel DDR4 Memory Technology
• 2 x DDR4 DIMM Slots
• Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
• Max. capacity of system memory: 32GB*
• Supports Intel® Extreme Memory Profile (XMP) 2.0
• 15μ Gold Contact in DIMM Slots
• BIOS
• 128Mb AMI UEFI Legal BIOS with multilingual GUI support
• ACPI 6.0 Compliant wake up events
• SMBIOS 2.7 Support
• DRAM, PCH 1.05V Voltage Multi-adjustment
• Graphics
• Supports Intel® UHD Graphics Built-in Visuals
• DirectX 12
• HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
• Dual graphics output: Support DVI-D and D-Sub ports by independent display controllers
• Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
• Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
• Supports HDCP 2.2 with DVI-D Port
• Audio
• 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec)
• Supports Surge Protection
• LAN
• PCIE x1 Gigabit LAN 10/100/1000 Mb/s
• 1 x Realtek RTL8111H
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Efficient Ethernet 802.3az
• Supports PXE
• Slots
• 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)
• 1 x PCI Express 2.0 x1 Slot
• Storage
• 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
• Connector
• 1 x TPM Header
• 1 x Chassis Intrusion and Speaker Header
• 1 x CPU Fan Connector (4-pin)*
• 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
• 1 x 24 pin ATX Power Connector
• 1 x 8 pin 12V Power Connector
• 1 x Front Panel Audio Connector
• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
• 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
• Rear Panel I/O
• 1 x PS/2 Mouse/Keyboard Port
• 1 x D-Sub Port
• 1 x DVI-D Port
• 4 x USB 2.0 Ports (Supports ESD Protection)
• 2 x USB 3.1 Gen1 Ports (Supports ESD Protection)
• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
• HD Audio Jacks: Line in / Front Speaker / Microphone
• Software and UEFI
• Software
• ASRock Motherboard Utility (A-Tuning)
• ASRock XFast LAN
• UEFI
• ASRock EZ Mode
• ASRock Full HD UEFI
• ASRock My Favorites in UEFI
• ASRock Instant Flash
• ASRock Internet Flash
• Support CD
• Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories
• Quick Installation Guide, Support CD, I/O Shield
• 2 x SATA Data Cables
• Hardware Monitor
• Temperature Sensing: CPU, Chassis/Water Pump Fans
• Fan Tachometer: CPU, Chassis/Water Pump Fans
• Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans
• Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans
• CASE OPEN detection
• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
• Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm
• Solid Capacitor design
• OS
• Microsoft® Windows® 10 64-bit / 11 64-bit
• Certifications
• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)
