MB 1851 H810M-H ASROCK, 2xDDR5 6400MHz, M.2, HDMI, PCIex16 4.0, PCIex1, 4xSATAIII, 4xUSB3.2Gen1, 7.1 ChannelsMB 1851 H810M-H ASROCK, 2xDDR5 6400MHz, M.2, HDMI, PCIex16 4.0, PCIex1, 4xSATAIII, 4xUSB3.2Gen1, 7.1 Channels

Цена со ДДВ: 5.490 ден.
Шифра: 18610
Баркод: 4711581490833
Производител: ASROCK
Гаранција: 720 дена
залиха: има на залиха
Спецификација

Model name: ASROCK H810M-H

Specifications:

  • CPU: LGA1851 socket: Support for Intel® Core™ Ultra Processors
    (Go to GIGABYTE's website for the latest CPU support list.)
    L3 cache varies with CPU
  • Chipset: Intel® H810 Express Chipset
  • Memory:
    • Support for DDR5 6400/5600 MT/s memory modules
    • 2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity)
    • Dual channel memory architecture
    • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 (operate in non-ECC mode)
    • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
    • Support for Extreme Memory Profile (XMP)
  • Onboard Graphics:
    • 1 x HDMI port, max resolution 4096x2160@60 Hz (HDMI 2.1, HDCP 2.3)
    • 1 x D-Sub port, max resolution 1920x1200@60 Hz
  • Audio: Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel
  • LAN: Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
  • Expansion Slots:
    • CPU: 1 x PCIe x16 slot (PCIe 4.0, x16)
    • Chipset: 1 x PCIe x1 slot (PCIe 3.0, x1)
  • Storage Interface:
    • 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2)
    • 4 x SATA 6Gb/s connectors
    • RAID 0, 1, 5, 10 support for SATA devices
  • USB:
    • 1 x USB Type-C® (USB 3.2 Gen 1, internal header)
    • 3 x USB 3.2 Gen 1 (1 rear, 2 internal header)
    • 3 x USB 2.0/1.1 (1 rear, 2 internal header)
    • 4 x USB 2.0/1.1 on back panel (via USB 2.0 Hub)
  • Internal I/O Connectors:
    • 1 x 24-pin ATX power
    • 1 x 8-pin ATX 12V power
    • 1 x CPU fan header
    • 2 x system fan headers
    • 2 x addressable RGB Gen2 headers
    • 1 x M.2 Socket 3
    • 4 x SATA 6Gb/s
    • 1 x front panel header
    • 1 x front panel audio
    • 1 x S/PDIF Out
    • 1 x USB Type-C® (USB 3.2 Gen 1)
    • 1 x USB 3.2 Gen 1
    • 1 x USB 2.0/1.1
    • 1 x TPM header
    • 1 x serial port header
    • 1 x Clear CMOS jumper
  • Back Panel Connectors:
    • 1 x PS/2 keyboard/mouse
    • 1 x HDMI
    • 1 x D-Sub
    • 1 x USB 3.2 Gen 1
    • 5 x USB 2.0/1.1
    • 1 x RJ-45
    • 3 x audio jacks
  • I/O Controller: iTE® I/O Controller Chip
  • H/W Monitoring:
    • Voltage detection
    • Temperature detection
    • Fan speed detection
    • Water cooling flow rate detection
    • Fan fail warning
    • Fan speed control
  • BIOS:
    • 1 x 256 Mbit flash
    • AMI UEFI BIOS
    • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Bundled Software:
    • Norton® Internet Security (OEM)
    • LAN bandwidth management software
  • Operating System:
    • Windows 11 64-bit
    • Windows 10 64-bit
  • Form Factor: Micro ATX (24.4cm x 21.5cm)
