MB AM5 B650 STEEL LEGEND ASROCK 4xDDR5 7200Mhz (O.C), HDMI, DP, PCI-Ex16 5.0, 1xPCI-Ex16 3.0, M.2 PCIe 5.0, 2xM.2 4.0, 4xSATAIII, Wi-Fi 6E, BT

Цена со ДДВ: 13.820 ден.
Шифра: 06414
Баркод: 4710483944598
Производител: ASROCK
Гаранција: 1080 дена
залиха: нема на залиха
Спецификација

Model Name: ASROCK B650 STEEL LEGEND

Specification :

  • CPU Support: AMD Socket AM5 Ryzen™ 9000, 8000, and 7000 Series Processors*
  • Chipset: AMD B650
  • Memory:
    • Dual Channel DDR5 Memory Technology
    • 4 x DDR5 DIMM Slots
    • Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)
    • Max. Capacity: 256GB
    • Supports XMP and EXPO memory profiles
  • BIOS: 256Mb AMI UEFI Legal BIOS with GUI support
  • Graphics:
    • Integrated AMD RDNA™ graphics (support varies by CPU)
    • 1 x HDMI 2.1 with HDR, HDCP 2.3, up to 4K 120Hz
    • 1 x DisplayPort 1.4 with DSC, HDCP 2.3, up to 4K 120Hz
  • Audio:
    • 7.1 CH HD Audio (Realtek ALC4082)
    • Impedance Sensing on Rear Out
    • Nahimic Audio
  • LAN:
    • 2.5 Gigabit LAN (Dragon RTL8125BG)
    • Smart Auto Adjust Bandwidth, Visual Network Usage
  • Wireless LAN:
    • 802.11axe Wi-Fi 6E
    • Dual-Band 2x2 with 6GHz support
    • Bluetooth 5.2
  • Slots:
    • CPU: 1 x PCIe 5.0 x16 Slot
    • Chipset: 1 x PCIe 3.0 x16 Slot, 1 x PCIe 4.0 x1 Slot, 1 x Vertical M.2 Socket (Key E)
    • Supports AMD CrossFire™
  • Storage:
    • CPU: 1 x PCIe Gen5x4 M.2, 1 x PCIe Gen4x4 M.2
    • Chipset: 1 x PCIe Gen4x4 M.2, 2 x SATA3 (ASM1061)
  • RAID:
    • SATA: RAID 0, RAID 1
    • NVMe: RAID 0, RAID 1, RAID 10
  • USB:
    • Rear: 1 x USB 3.2 Gen2x2 Type-C, 1 x USB 3.2 Gen2 Type-A, 4 x USB 3.2 Gen1 Type-A, 4 x USB 2.0
    • Front: 1 x USB 3.2 Gen1 Type-C, 4 x USB 3.2 Gen1 Type-A, 4 x USB 2.0
  • Connectors:
    • 1 x SPI TPM Header, 1 x Power LED and Speaker Header
    • RGB Headers, Fan Connectors with Smart Fan Control
    • 2 x 8 pin 12V Power Connectors
  • Rear Panel I/O:
    • 2 x Antenna Ports, HDMI, DisplayPort
    • USB Ports, Optical SPDIF Out
    • LAN, Audio Jacks, BIOS Flashback
  • Software and UEFI:
    • ASRock Motherboard Utility (A-Tuning)
    • ASRock Polychrome SYNC, Full HD UEFI
  • Form Factor: ATX (12.0-in x 9.6-in, 30.5 cm x 24.4 cm), 8 Layer PCB
  • OS Support: Microsoft Windows® 10/11 64-bit
  • Certifications: FCC, CE, ErP/EuP ready
