Model name: TP-LINK ARCHER AX12

Specifications:

• Standards and Protocols:
  • Wi-Fi 6
  • IEEE 802.11ax/ac/n/a 5 GHz
  • IEEE 802.11n/b/g 2.4 GHz
• WiFi Speeds: AX1500
  • 5 GHz: 1201 Mbps (802.11ax)
  • 2.4 GHz: 300 Mbps (802.11n)
• WiFi Range: 2-3 Bedroom Houses
  • 4× Fixed High-Performance Antennas
  • Beamforming: Concentrates wireless signal strength towards clients to expand WiFi range
• WiFi Capacity: High
  • Dual-Band: Allocate devices to different bands for optimal performance
  • Airtime Fairness: Improves network efficiency by limiting excessive occupation
  • 4 Streams: Connect your devices to more bandwidth
• Working Modes:
  • Router Mode
  • Access Point Mode
• Security:
  • Network Security:
    • SPI Firewall
    • Access Control
    • IP & MAC Binding
    • Application Layer Gateway
  • Guest Network:
    • 1× 5 GHz Guest Network
    • 1× 2.4 GHz Guest Network
  • VPN Server:
    • OpenVPN
    • PPTP
  • WiFi Encryption:
    • WPA2-PSK
    • WPA2-PSK/WPA-PSK
    • WPA3-Personal
    • WPA3-Personal/WPA2-PSK
    • WPA2-Enterprise
    • WPA/WPA2-Enterprise encryptions
• Hardware:
  • Ethernet Ports:
    • 1× Gigabit WAN Port
    • 3× Gigabit LAN Ports
  • Buttons: WPS/Reset Button
  • Power: 12 V ⎓ 1 A
• Software:
  • Protocols:
    • IPv4
    • IPv6
  • Parental Controls:
    • URL Filtering
    • Time Controls
  • WAN Types:
    • Dynamic IP
    • Static IP
    • PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
  • Quality of Service: QoS by Device
  • Cloud Service:
    • Auto Firmware Upgrade
    • OTA Firmware Upgrade
    • TP-Link ID
    • DDNS
  • NAT Forwarding:
    • Port Forwarding
    • Port Triggering
    • DMZ
    • UPnP
  • IPTV:
    • IGMP Proxy
    • IGMP Snooping
    • Bridge
    • Tag VLAN
  • DHCP:
    • Address Reservation
    • DHCP Client List
    • Server
  • DDNS:
    • TP-Link
    • NO-IP
    • DynDNS
• Other:
  • System Requirements:
    • Microsoft Windows 98SE/NT/2000/XP/Vista/7/8/8.1/10/11
    • MAC OS, NetWare, UNIX or Linux
    • Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
    • Cable or DSL Modem
    • Subscription with an internet service provider (for internet access)
  • Certifications: FCC, CE, RoHS
  • Environment:
    • Operating Temperature: 0℃~40℃ (32℉ ~104℉)
    • Storage Temperature: -40℃~60℃ (-40℉ ~140℉)
    • Operating Humidity: 10%~90% non-condensing
    • Storage Humidity: 5%~90% non-condensing
• Test Data:
  • WiFi Transmission Power:
    • CE: <20 dBm (2.4 GHz), <23 dBm (5.15 GHz~5.25 GHz)
    • FCC: <30 dBm (2.4 GHz & 5.15 GHz~5.825 GHz)
  • WiFi Reception Sensitivity:
    • 5 GHz:
      • 11a 6 Mbps: -95 dBm
      • 11a 54 Mbps: -79 dBm
      • 11ac VHT20_MCS0: -96 dBm
      • 11ac VHT20_MCS8: -66 dBm
      • 11ac VHT40_MCS0: -94 dBm
      • 11ac VHT40_MCS9: -63 dBm
      • 11ac VHT80_MCS0: -91 dBm
      • 11ac VHT80_MCS9: -60 dBm
      • 11ax HE20_MCS0: -95 dBm
      • 11ax HE20_MCS11: -66 dBm
      • 11ax HE40_MCS0: -92 dBm
      • 11ax HE40_MCS11: -65 dBm
      • 11ax HE80_MCS0: -89 dBm
      • 11ax HE80_MCS11: -62 dBm
    • 2.4 GHz:
      • 11g 6 Mbps: -96 dBm
      • 11g 54 Mbps: -80 dBm
      • HT20-MCS0: -97 dBm
      • HT20-MCS7: -78 dBm
      • HT40-MCS0: -94 dBm
      • HT40-MCS7: -75 dBm
