Model name: CUDY AP1300D

Specifications:

• CPU Details: 880 MHz Dual-Core CPU
• Memory/Storage:
  • Flash/ROM: 16 MB (128 Mbit) NOR
  • DDR/RAM: 128 MB (1 Gbit) DDR3
• Wireless:
  • 5 GHz Wi-Fi Speed: 867 Mbps
  • 2.4 GHz Wi-Fi Speed: 300 Mbps
  • 5 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
  • 2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
  • Wi-Fi Antennas: 4× Fixed
  • 5 GHz Antenna Gain Max: 5.3 dBi
  • 2.4 GHz Antenna Gain Max: 5.2 dBi
  • FEM or PA/LNA:
    • 5 GHz: 2× Internal
    • 2.4 GHz: 2× Internal
  • Beamforming: True
  • Range Performance: Max 170 m (558 ft) (tested in open-space)
  • Wall Performance:
    • 2× wooden walls < 10 cm thick
    • 1× concrete wall < 20 cm thick
• Interfaces:
  • Gigabit RJ45 Ports: 1
  • Ethernet Notes: Accepts PoE powering
• LED Indicators: 5 GHz Wi-Fi, 2.4 GHz Wi-Fi, WPS, LAN, Internet, Power
• Physical Buttons: Reset Button, Power On/Off Button
• Power Input: DC Jack, PoE via Ethernet Port
• Power Methods: DC / Passive PoE / 802.3at/af PoE
• DC Input: 12V 1A
• Passive PoE Input: 12V ~ 57V
• Included Power Adapter:
  • Input: 100 ~ 240 V, 50/60 Hz AC
  • Output: 12V 1A DC
• Max Power Consumption: 11W (PoE), 8.5W (DC)
• Reliability (EMS): ESD: Contact 4kV, Air 8kV
• Environment:
  • Operating Temperature: -10℃ ~ 65℃ (14℉ ~ 149℉)
  • Storage Temperature: -40℃ ~ 70℃ (-40℉ ~ 158℉)
  • Operating Humidity: 10% ~ 90% (non-condensing)
  • Storage Humidity: 5% ~ 90% (non-condensing)
• Certifications: FCC, CE
