UPS 2200VA / 1200W POWERWALKER VI 2200 SHL, 2xSHUKO, 2x IEC C13, USB, RJ11, 10120098

Цена со ДДВ: 11.590 ден.
Шифра: 12139
Баркод: 4260074976502
Производител: POWERWALKER
Гаранција: 360 дена
залиха: има на залиха
Спецификација

Model Name: PowerWalker VI 2200 SHL LCD

2200 VA / 1200 W line-interactive UPS · Tower form factor
LCD touch panel · USB HID support · Multiple Type F & IEC outlets

Features

  • Line-interactive (VI) UPS with 2200 VA / 1200 W power capacity
  • Human Interface Device (HID) supported for native OS integration
  • LCD touch panel for easy parameter monitoring and navigation
  • Data line surge protection via RJ-11 and RJ-45 ports (100 Mbit)
  • Several output sockets: Type F, Type E, IEC with C14 input connector
  • Automatic Voltage Regulator (AVR) for stable output voltage
  • Advanced fan logic for reduced noise in LINE mode at low load
  • Includes WinPower monitoring software via USB Type B connection

Specification

  • UPS type: Line-Interactive (VI)
  • Phases (IN-OUT): 1-1
  • Form factor: Tower
  • Power capacity: 2200 VA / 1200 W
  • Output power factor: 0.55
  • Input voltage range: 170–280 VAC ±7%
  • Input frequency range: 50 Hz or 60 Hz (self-adaptive)
  • Waveform: Simulated sine wave
  • Nominal output voltage: 230 VAC
  • Output frequency (battery mode): ±1 Hz
  • Input connector: C14
  • Output sockets: 2 × Type F (CEE 7/3), 2 × IEC C13
  • LINE mode efficiency (full load): 95.0%
  • Battery mode efficiency (full load): 60.0%
  • Transfer time (AC/Line to battery): 4–8 ms
  • Data line protection: RJ-11 port, RJ-45 port (100 Mbit)
  • Additional features: LCD display, circuit breaker reset, HID support, AVR
  • IEC 62040-3 classification: VI-SY-333
  • Batteries: 2 × 12.0 V / 9.0 Ah
  • DC voltage: 2 × 12.0 V
  • Charger current: 1.2 A
  • Recharge time: 4 h to 90%
  • Full load backup time: 0.5 min
  • Half load backup time: 5.0 min
  • Communication: USB Type B – for
