Model name: CUDY FS1010PG

Specification :

• Interfaces
  • Gigabit RJ45 Ports: 2
  • 10/100 Mbps RJ45 Ports: 8
  • 10/100 Mbps RJ45 PoE Ports: #1~#8
  • Max Power on a Single PoE Port: 30W
  • PoE Port Notes: The PoE ports comply with IEEE 802.3at/af standards.
  • Extend Mode Ports: #1~#8
  • VLAN Mode Ports: #1~#8
• LED
  • Indicators: Power
  • Indicators: Link/ACT of Each Ethernet Port
  • Indicators: DIP Mode (SW)
• Power Interfaces: AC Inlet
• Physical Buttons: VLAN / Default / Extend DIP Switch
• Performance
  • Copper Speed and Distance:
    • Cat. 3 or higher cable: 100 meters at 10 Mbps
    • Cat. 5 or higher cable: 100 meters at 100 Mbps
    • Cat. 5e or higher cable: 100 meters at Gigabit
    • Cat. 5e or higher cable: 250 meters at 10 Mbps
  • Copper Speed and Distance Note: Gigabit speed is only available on the uplink ports. 250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated.
  • MAC Address Table: 2048
  • Max Switching Capacity: 5.6 Gbps
  • Max Forwarding Rate: 4.166 Mpps
  • Packet Buffer: 2 Mbit
• Power
  • Power Methods: AC
  • Power Input: 100-240V~, 50/60Hz
  • Power Supply: 120W
  • Max Power Excluding PoE: 5W
• Switching
  • 802.3 Protocols:
    • 802.3i 10BASE-T
    • 802.3u 100BASE-TX
    • 802.3ab 1000BASE-T
    • 802.3x Flow Control
    • 802.3af PoE
    • 802.3at PoE
• Reliability
  • Grounding Methods: Three-Prong Plug
• Environment
  • Operating Temperature: 0~40 ℃ (32~104 ℉)
  • Storage Temperature: -40~70 ℃ (-40~158 ℉)
  • Operating Humidity: 10~90% non-condensing
  • Storage Humidity: 10~95% non-condensing
