Model Name: GIGABYTE B760M DS3H DDR5

Specification :

• CPU: LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
• L3 cache: Varies with CPU
• Chipset: Intel® B760 Express Chipset
• Memory:
  • 14th and 13th Generation Intel® Core™ i9/i7 Processors: Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.)/ 5600/5200/4800/4400 MT/s memory modules
  • 13th Generation Intel® Core™ i5/i3 and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors: Support for DDR5 4800/4400 MT/s memory modules
  • 4 x DDR5 DIMM sockets: Supporting up to 256 GB (64 GB single DIMM capacity) of system memory
  • Dual channel memory architecture:
  • Support for ECC Un-buffered DIMM: 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  • Support for non-ECC Un-buffered DIMM: 1Rx8/2Rx8/1Rx16 memory modules
  • Support for Extreme Memory Profile (XMP) memory modules:
• Onboard Graphics:
  • Integrated Graphics Processor-Intel® HD Graphics support:
  • 1 x D-Sub port: Supporting a maximum resolution of 1920x1200@60 Hz
  • 1 x HDMI port: Supporting a maximum resolution of 4096x2160@60 Hz
  • 1 x DisplayPort: Supporting a maximum resolution of 4096x2304@60 Hz
• Audio:
  • Realtek® Audio CODEC:
  • High Definition Audio:
  • 2/4/5.1/7.1-channel: (You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings)
  • Support for S/PDIF Out:
• LAN: Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
• Expansion Slots:
  • CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
  • Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
• Storage Interface:
  • CPU: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
  • Chipset: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB), 4 x SATA 6Gb/s connectors
• RAID: RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
• USB:
  • Chipset: 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support, 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header), 2 x USB 2.0/1.1 ports on the back panel
  • Chipset + 2 USB 2.0 Hubs: 4 x USB 2.0/1.1 ports available through the internal USB headers
• Internal I/O Connectors:
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x CPU fan header
  • 3 x system fan headers
  • 1 x addressable LED strip header
  • 1 x RGB LED strip header
  • 2 x M.2 Socket 3 connectors
  • 4 x SATA 6Gb/s connectors
  • 1 x front panel header
  • 1 x front panel audio header
  • 1 x USB 3.2 Gen 1 header
  • 2 x USB 2.0/1.1 headers
  • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
  • 1 x serial port header
  • 1 x parallel port header
  • 1 x S/PDIF Out header
  • 1 x Q-Flash Plus button
  • 1 x reset jumper
  • 1 x Clear CMOS jumper
• Back Panel Connectors:
  • 2 x USB 2.0/1.1 ports
  • 1 x PS/2 keyboard/mouse port
  • 1 x D-Sub port
  • 1 x HDMI port
  • 2 x DisplayPorts
  • 3 x USB 3.2 Gen 1 ports
  • 1 x USB Type-C® port, with USB 3.2 Gen 2 support
  • 1 x RJ-45 port
  • 3 x audio jacks
• I/O Controller: iTE® I/O Controller Chip
• H/W Monitoring:
  • Voltage detection
  • Temperature detection
  • Fan speed detection
  • Water cooling flow rate detection
  • Fan fail warning
  • Fan speed control (Whether the fan speed control function is supported will depend on the cooler you install)
• BIOS:
  • 1 x 128 Mbit flash
  • Use of licensed AMI UEFI BIOS
  • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
• Unique Features:
  • Support for GIGABYTE Control Center (GCC) (Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications)
  • Support for Q-Flash
  • Support for Q-Flash Plus
• Bundled Software:
  • Norton® Internet Security (OEM version)
  • LAN bandwidth management software
• Operating System:
  • Support for Windows 11 64-bit
  • Support for Windows 10 64-bit
• Form Factor: Micro ATX Form Factor; 24.4cm x 24.4cm
