Model name: SAMSUNG 990 PRO

Specifications:

• Application: Client PCs, Game Consoles
• Rated Capacity: 2,000GB (1GB=1 Billion bytes by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
• Form Factor: M.2 (2280)
• Interface: PCIe Gen 4.0 x4, NVMe 2.0
• Dimension (WxHxD): 80 x 22 x 2.3 mm
• Weight: Max 9.0g
• Storage Memory: Samsung V-NAND 3-bit MLC
• Controller: Samsung in-house Controller
• Cache Memory: Samsung 2GB Low Power DDR4 SDRAM
• Sequential Read: Up to 7,450 MB/s * Performance may vary based on system hardware & configuration
• Sequential Write: Up to 6,900 MB/s * Performance may vary based on system hardware & configuration
• Random Read (4KB, QD32): Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration
• Random Write (4KB, QD32): Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
• Random Read (4KB, QD1): Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
• Random Write (4KB, QD1): Up to 80,000 IOPS * Performance may vary based on system hardware & configuration
• Average Power Consumption (system level): Average: 5.5 W, Maximum: 8.5 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
• Power consumption (Idle): Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration
• Allowable Voltage: 3.3 V ± 5 %
• Reliability (MTBF): 1.5 Million Hours
• Operating Temperature: 0 - 70 ℃
• Shock: 1,500 G & 0.5 ms (Half sine)
