Ubiquiti UAP-AC-PRO UniFi Wireless Access Point

The Ubiquiti UAP-AC-PRO is a professional dual-band UniFi access point designed to provide reliable wireless connectivity in homes, offices, and business environments. It supports 2.4 GHz and 5 GHz Wi-Fi, offers combined speeds of up to 1300 Mbps, and includes two Gigabit Ethernet ports with Power over Ethernet support.

Key Features

• Dual-band Wi-Fi: Supports both 2.4 GHz and 5 GHz wireless networks.
• AC1300 performance: Provides a maximum combined Wi-Fi data rate of up to 1300 Mbps.
• 3x3 MIMO: Uses three antennas to improve wireless throughput and network reliability.
• Two Gigabit Ethernet ports: Includes two RJ-45 ports supporting 10, 100, and 1000 Mbps speeds.
• Power over Ethernet: Supports PoE installation and includes a PoE adapter.
• Wide indoor coverage: Provides an indoor range of up to 122 m.
• Flexible mounting: Includes a mounting kit for convenient installation.
• Built-in USB port: Features one USB 2.0 port.
• Security support: Compatible with AES, TKIP, WEP, WPA, and WPA2 security protocols.

Wireless Performance

The UAP-AC-PRO supports dual-band wireless networking and is suitable for connecting computers, mobile devices, smart appliances, and other network equipment. Its maximum combined Wi-Fi data rate is 1300 Mbps, while the three-antenna MIMO configuration helps improve performance when multiple devices are connected simultaneously.

Network Connectivity

Two RJ-45 Ethernet ports are available for wired network connections. Both ports support 10 Mbps, 100 Mbps, and 1000 Mbps data rates, allowing the access point to integrate with Gigabit Ethernet networks.

Power and Installation

The access point supports Power over Ethernet, helping simplify deployment by combining power and network connectivity through an Ethernet cable. A PoE adapter and mounting kit are included. The device operates with a 48 V input and has a maximum power consumption of 9 W.

Security

The UAP-AC-PRO supports several wireless security standards, including AES, TKIP, WEP, WPA, and WPA2. A reset button is also included for restoring the device to its default settings when required.

Technical Specifications

• Brand: Ubiquiti
• Model: UAP-AC-PRO
• Product family: UniFi
• Product type: Wireless access point
• Product colour: White
• Wireless bands: 2.4 GHz and 5 GHz
• Wi-Fi standard: 802.11ac
• MIMO configuration: 3x3
• Maximum Wi-Fi data rate: 1300 Mbps
• Maximum indoor range: Up to 122 m
• Number of antennas: 3
• Maximum antenna gain: 3 dBi
• Ethernet ports: 2 x RJ-45
• Ethernet data rates: 10/100/1000 Mbps
• Power over Ethernet: Supported
• PoE adapter: Included
• AC input voltage: 48 V
• Maximum power consumption: 9 W
• USB ports: 1 x USB 2.0
• Reset button: Yes
• Mounting kit: Included
• Operating temperature: -10 to 70 °C
• Operating humidity: 5% to 95% relative humidity
• Dimensions: 196.7 × 196.7 × 35 mm
• Weight: 350 g
• Certifications: CE, FCC, and IC
• HS code: 85176990
• Package quantity: 1 unit

Summary

The Ubiquiti UAP-AC-PRO is a dual-band AC1300 UniFi access point featuring 3x3 MIMO, two Gigabit Ethernet ports, PoE support, and indoor coverage of up to 122 m. With an included PoE adapter and mounting kit, it is a practical solution for extending or creating a reliable wireless network in residential and business environments.
