Cudy GS1024E 24-Port Gigabit Managed Switch

The Cudy GS1024E is a 24-port Gigabit Ethernet switch for expanding wired network connectivity in offices and other network environments. It supports web management, SNMP, and Cudy app and cloud control. VLAN, QoS, port mirroring, static link aggregation, and loop detection and prevention help manage network traffic and configuration.

The switch includes Managed, VLAN, and Extend preset modes and supports desktop or rack-mount installation. Extend Mode enables transmission up to 250 metres on supported ports; in Managed Mode, this distance is available when the port speed is set to 10 Mbps in the software.

Specifications

• Brand: Cudy
• Model: GS1024E
• Ports: 24 × Gigabit Ethernet (10/100/1000 Mbps)
• Management: Web management, SNMP, Cudy app, cloud control
• Preset modes: Managed, VLAN, Extend
• VLAN features: 802.1Q, MTU, and port-based VLAN; up to 4096 VLANs
• QoS: 802.1p, DSCP, and port-based
• Other features: Port mirroring, static aggregation, loop detection and prevention, DHCP snooping, IGMP snooping
• MAC address table: 8192 entries
• Switching capacity: 48 Gbps
• Forwarding rate: 35.712 Mpps
• Jumbo frame: 15 KB
• Packet buffer: 4 Mbit
• Maximum copper distance: Up to 100 m at 10 Mbps over Cat 3 or higher; up to 100 m at 100 Mbps over Cat 5 or higher; up to 100 m at Gigabit over Cat 5e or higher; up to 150 m at Gigabit over Cat 6 or higher
• Extended copper distance: Up to 250 m at 10 Mbps on supported ports, subject to the selected mode and configuration
• Installation: Desktop or rack-mount
• Housing: Metal
• Dimensions (W × D × H): 440 × 180 × 44 mm (17.32 × 7.09 × 1.73 in)
