Model name: POWERWALKER 10121068

Specifications:

• Type: Line-Interactive (VI)
• Phases (IN-OUT): 1-1
• Form Factor: Tower
• Power Capacity: 1000VA / 600W
• Output Power Factor: 0.60
• Input:
  • Input Voltage Range: 162-290 VAC
  • Frequency Range: 50Hz or 60Hz (self-adaptive)
• Output:
  • Waveform: Simulated Sine Wave
  • Nominal Output Voltage: 230 VAC
  • Frequency (Battery Mode): ±0.05Hz
  • Output Power Factor: 0.60
• Connectors:
  • Input Connector: CEE 7/7
  • Type F (CEE 7/3): 3
• Technical Details:
  • LINE Mode Efficiency [%] (Full Load): 96.5%
  • Transfer Time (AC / Line Mode to Battery Mode) [ms]: 4ms
  • Additional Features: Circuit Breaker Reset, HID – Human Interface Device, AVR – Automatic Voltage Regulator, Cold-Start Function
  • IEC 62040-3 Classification: VI-SY-333
• Batteries and Autonomy:
  • Batteries: 2x 12.0V/5.0Ah
  • DC Voltage: 2x 12.0V
  • Recharge Time: 8h to 90%
  • Full Load Backup Time [min]: 1.0 minute
  • Half Load Backup Time [min]: 7.0 minutes
  • Charger: 0.7A
• Communication:
  • Communication: USB Type B – for Monitoring Software
  • Software: PowerMaster
• Management and Environment:
  • Software: PowerMaster
  • Communication: USB Type B – for Monitoring Software
  • Noise Level: < 30dB
  • Fan Logic: No fan
  • Temperature: 0°C – 40°C
  • Humidity: 0% – 90% RH (non-condensing)
  • IP Rating: IP 20
