Model name: AMD RYZEN 5 8600G

Specification:

• Series Ryzen 8000 Series
• Form Factor Desktops
• AMD PRO Technologies No
• Consumer Use Yes
• Regional Availability Global
• Former Codename Phoenix
• Architecture Zen 4
• # of CPU Cores 6
• Multithreading (SMT) Yes
• # of Threads 12
• Max. Boost Clock Up to 5 GHz
• Base Clock 4.3 GHz
• L2 Cache 6 MB
• L3 Cache 16 MB
• Default TDP 65W
• AMD Configurable TDP (cTDP) 45-65W
• Processor Technology for CPU Cores TSMC 4nm FinFET
• CPU Compute Die (CCD) Size 178mm²
• Unlocked for Overclocking Yes
• AMD EXPO™ Memory Overclocking Technology Yes
• Precision Boost Overdrive Yes
• Curve Optimizer Voltage Offsets Yes
• AMD Ryzen™ Master Support Yes
• CPU Socket AM5
• Supporting Chipsets A620, X670E, X670, B650E, B650, X870E, X870, B840, B850
• CPU Boost Technology Precision Boost 2
• Instruction Set x86-64
• Supported Extensions AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
• Max. Operating Temperature (Tjmax) 95°C
• OS Support Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit
• Native USB 4 (40Gbps) 2
• Native USB 3.2 Gen 2 (10Gbps) 2
• Native USB 2.0 (480Mbps) 1
• PCI Express® Version PCIe® 4.0
• Native PCIe® Lanes (Total/Usable) 20, 16
• NVMe Support Boot, RAID0, RAID1
• System Memory Type DDR5
• Memory Channels 2
• Max. Memory 256 GB
• System Memory Subtype UDIMM
• Max Memory Speed 2x1R DDR5-5200, 2x2R DDR5-5200, 4x1R DDR5-3600, 4x2R DDR5-3600
• Graphics Model AMD Radeon™ 760M
• Graphics Core Count 8
• Graphics Frequency 2800 MHz
• DirectX® Version 12
• DisplayPort™ Version 2.1
• DisplayPort Extensions Adaptive-Sync, HDR Metadata, UHBR10
• DisplayPort Max Refresh Rates (SDR) 7680x4320 @ 60Hz, 3840x2160 @ 240Hz, 3440x1440 @ 360Hz, 2560x1440 @ 480Hz, 1920x1080 @ 600Hz
• DisplayPort Max Refresh Rates (HDR) 7680x4320 @ 60Hz, 3840x2160 @ 240Hz, 3440x1440 @ 360Hz, 2560x1440 @ 480Hz, 1920x1080 @ 600Hz
• HDMI® Version 2.1
• HDCP Version Supported 2.3
• USB Type-C® DisplayPort™ Alternate Mode Yes
• Multi-Monitor Support Yes
• Max Displays 4
• AMD FreeSync™ Yes
• Wireless Display Miracast
• Max Video Encode Bandwidth (SDR) 1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1, 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1
• Max Video Decode Bandwidth 1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9, 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264, 2160p300 8bpc H.264, 4320p75 8bpc H.264, 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265, 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1
• AMD SmartAccess Memory Available
