Model Name: TP-LINK ARCHER C20

Specification

• WIRELESS
• Standards: Wi-Fi 5: IEEE 802.11ac/n/a 5 GHz, IEEE 802.11n/b/g 2.4 GHz
• WiFi Speeds: AC750 5 GHz: 433 Mbps (802.11ac), 2.4 GHz: 300 Mbps (802.11n)
• WiFi Range: 2 Bedroom Houses 3× Fixed Antennas
• Multiple antennas form a signal-boosting array to cover more directions and large areas
• WiFi Capacity: Medium Dual-Band, Allocate devices to different bands for optimal performance
• Working Modes: Router Mode, Access Point Mode, Range Extender Mode
• SECURITY
• Network Security: SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway
• Guest Network: 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network
• WiFi Encryption: WEP, WPA, WPA2, WPA/WPA2-Enterprise (802.1x)
• HARDWARE
• Processor: Single-Core CPU
• Ethernet Ports: 1× 10/100 Mbps WAN Port, 4× 10/100 Mbps LAN Ports
• Buttons: WPS/Wi-Fi Button, Power On/Off Button, Reset Button
• Power: 9 V ⎓ 0.6 A
• SOFTWARE
• Protocols: IPv4, IPv6
• Parental Controls: URL Filtering, Time Controls
• WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
• Quality of Service: QoS by Device
• NAT Forwarding: Virtual Server, Port Forwarding, Port Triggering, DMZ, UPnP
• IPTV: IGMP Proxy, IGMP Snooping
• DHCP: Address Reservation, DHCP Client List, Server
• DDNS: NO-IP, Comex, DynDNS
• Management: Tether App, Webpage
• TEST DATA
• WiFi Transmission Power: CE: <20dBm(2.4GHz), <23dBm(5GHz)
• WiFi Reception Sensitivity:
• 5GHz: 11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm, 11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9: -62dBm
• 2.4GHz: 11g 54M: -76dBm; 11n HT20 MCS7: -73dBm, 11n HT40 MCS7: -71dBm
