NET INJECTOR CUDY POE++ 60W POE300

Цена со ДДВ: 2.190 ден.
Шифра: 17490
Баркод: 6971690790585
Производител: CUDY
Гаранција: 720 дена
залиха: има на залиха
Спецификација

Model Name: CUDY POE300

Specifications

  • No. of Channels: 1
  • Pass Through Data Rates: 10/100/1000 Mbps
  • Power over Ethernet Output:
    • Pin Assignment and Polarity: 1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-)
    • Output Power Voltage: 53Vdc
    • User Port Power: 60W
  • Input Power Requirements:
    • AC Input Voltage: 100 to 240 VAC
    • AC Input Current: 0.5A 100-240 VAC
    • AC Frequency: 50 to 60 Hz
  • Dimensions: 145mm x 60mm x 40mm
  • Indicators:
    • System Indicator: AC Power
    • User Indicator: Channel Power
  • Connectors: Shielded RJ-45, EIA 568A and 568B
  • Regulatory Compliance: IEEE 802.3af (15.4W), IEEE 802.3at (30W), IEEE 802.3bt (60W)

Environmental Conditions

  • Operating Ambient Temperature: 0 to 40℃
  • Operating Humidity: Maximum 85%, Non-condensing
  • Storage Temperature: -40 to 60℃
  • Storage Humidity: Maximum 85%, Non-condensing
