Model Name: CUDY AP1200

Specification :

• CPU: 580 MHz Processor
• Flash: 8 MB (64 Mbit)
• DDR: 64 MB (512 Mbit)

• Interface:
  • 1× 10/100Mbps Ethernet (RJ-45) Port (Support Passive PoE)
  • 1× Reset Button
  • 1× WPS Button

• Power Supply: 24 V Passive PoE (+4,5pins; -7,8pins)

• Dimensions:
  • AP Body: 240×100×53.7 mm
  • Antennas: 197.5×21.6×15.5 mm
  • Height of AP with Antennas installed: 438 mm

• Antenna Type: 2× Detachable Omni-directional Antennas

• Mounting: Pole/Wall Mounting (Kit included)

• Wireless Function:
  • Wireless Standard: Wi-Fi 5 (802.11ac/n/g/b/a)
  • Frequency: 5 GHz, 2.4 GHz
  • Signal Rate:
    • 5 GHz: Up to 867 Mbps
    • 2.4 GHz: Up to 300 Mbps
  • Bandwidth: 20/40/80 MHz
  • Wireless Functions:
    • Multiple SSID
    • Enable/Disable Wireless Radio
    • Transmit Power Control
    • QoS (WMM)
    • Band Steering
    • MU-MIMO
    • Beamforming
    • Rate Limit
    • Reboot Schedule
    • Wireless Schedule
  • Wireless Encryption: WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK
  • Security:
    • Access Control
    • Mac Filtering
    • Wireless Isolation Clients

• Weather-Proof:
  • Dust/Water-Proof: IP65 (Protection against any dust and low-pressure water from any directions)
  • Lightning Protection: 4 KV Lightning/Surge protection at the Ethernet port
  • ESD: 8 KV Contact / 15 KV Air ESD protection

• Working Temperatures:
  • Operating Temperatures: -20~60 °C (-4~140°F)
  • Extend: -40~65 °C (-40~149°F) (Booted up in advance. Performance may drop slightly.)
  • Storage Temperature: -40–70 °C (-40–158 °F)

• Operating Mode:
  • Access Point Mode
  • Router Mode
  • RE Mode
  • WISP Mode

• Environment:
  • Operating Temperatures: -20~60 °C (-4~140°F) ext. -40~65 °C (-40~149°F)
  • Storage Temperature: -40–70 °C (-40–158 °F)
  • Operating Humidity: 10–90% RH non-condensing
  • Storage Humidity: 5–90% RH non-condensing
