Model Name: AIO NZXT Kraken 280 RGB

Cap

• Material: Aluminum and plastic
• Display Orientation: Software adjustable Default, +90, +180, and -90 Degrees
• Display Panel Active Area: 1.54" (39.1mm)
• Display Resolution: 240 x 240 px
• Display Brightness: 300 cd/m²
• Display Panel Type: Transmissive TFT, 262K color

Water Block

• Dimensions: Diameter: 74.7mm, H: 55.97mm
• Material (Block): Copper
• Material (Housing): Plastic

Pump

• Motor Speed: 800 - 2,800 ± 300RPM
• Power: 12V DC, 0.3A

Radiator

• Dimensions: 143mm x 315mm x 30mm
• Material: Aluminum

Tube

• Length: 400mm
• Material: Ultra-low Evaporation Rubber with Nylon Braided Sleeve

Fan Specs

• Model: F140 RGB Core Fans
• Quantity: 2
• Dimension: 140 x 140 x 26mm
• Speed: 500-1,500 ± 150 RPM
• Air Flow: 90.79 CFM
• Air Pressure: 3.22 mm H2O
• Noise: 34.48 dBA
• Bearing: Fluid Dynamic Bearing
• Power Consumption: 12 V DC, 0.24 A, 2.88 W
• Connector: 4-pin PWM

RGB Controller

• Dimensions: 63.2 x 53.2 x 12.8mm
• Weight: 52.8g
• Mounting: Magnet and 3M Dual Lock
• Connection Cables: 1x USB 2.0 internal connector, 1x SATA power cable
• Input Connector: 12V DC / 2.6A
• RGB Lighting Channels: 3
• Output Channel Voltage: 5V DC
• NZXT RGB Channel Output LED Qty.: Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels

Compatible Socket & CPU

• Intel Socket: Intel Socket LGA 1700 & 1200/115X
• Intel: Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
• AMD Socket: AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included)
• AMD: AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
