Main unit

• Height: 104 mm
• Width: 400 mm
• Depth: 85 mm
• Weight: 1.04 kg

Remote Control

• Height: 83 mm
• Width: 83 mm
• Depth: 10 mm

RIGHTSENSE TECHNOLOGIES

• Advanced technologies and design innovations that make video collaboration easy and automatic.

RightLight

• Low-light compensation
• Video noise reduction
• Low-light saturation optimization

RightSight

• Human figure detection
• Auto-frame participants at meeting start
• Auto-frame participants on-demand
• Auto-reframe when participants enter, leave, or change positions

RightSound

• Machine learning AI trained to distinguish human speech from other sounds
• AEC (Acoustic Echo Cancellation)
• VAD (Voice Activity Detector)
• Background noise suppression
• Auto-level loud and soft voices
• Peak-limiting algorithm eliminates even momentary speaker clipping to prevent distortion
• Anti-vibration enclosure

COMPATIBILITY AND INTEGRATIONS

• Plug-and-play USB connectivity
• Certifications
  • Certified for Skype™ for Business and ready for Teams
  • Zoom™ Certified
  • Tencent Certified
  • Certified for Google Hangouts Meet Hardware
• Compatibility
  • RingCentral: q
  • Microsoft Cortana
  • Cisco Jabber®
  • BlueJeans
  • BroadSoft™
  • Vidyo™
• and other video conferencing, recording, and broadcasting applications that support USB cameras TAA compliant. For applicable part numbers, visit www.logitech.com/support/meetup-taa-compliance

Camera

• Custom Logitech lens with 5x HD zoom and motorised pan (+/- 25°) and tilt (+/- 15°)
• Field of View: Diagonal: 120°, Horizontal: 113°, Vertical: 80.7°
• Total Room Coverage (field of view + pan and tilt): 163° wide x 110° tall
• 3 camera position presets
• RightSight auto-framing: Requires Windows 10 64-bit or macOS 10.14 or higher

Video Performance

• 4K Ultra HD video calling (up to 3840 x 2160 pixels @ 30 fps with customer-supplied USB 3.0 cable)
• 1080p Full HD video calling (up to 1920 x 1080 pixels @ 30 fps)
• 720p HD video calling (up to 1280 x 720 pixels @ 30 fps)

Microphone

• Integrated microphone with 3 beamforming elements
• Pickup Range
  • MeetUp: 4 m
  • With optional Expansion Mic: 5 m
• Sensitivity: -27 dB
• Microphone frequency response: 90Hz-16KHz for full voice reproduction and high intelligibility without noise
• Beamforming performance: Factory-paired, very low distortion broadside beamforming algorithm steers the microphones directly at the talker for the best voice pickup and noise reduction
• AEC (Acoustic Echo Cancellation)
• VAD (Voice Activity Detector)
• Microphone background noise suppression
• Microphone date rate: 32KHz sampling rate
• Recommended # of participants: 6
• Recommended # of participants with expansion mic: 8

Speaker

• Volume adjustable to 95 dB SPL at 1/2 meter peak
• Speaker sensitivity 86.5+/-3dB SPL at 1/2 meter
• Distortion: 200-300Hz < 3%, 3000 Hz -10KHz < 1%
• Patent-pending anti-vibration enclosure improves voice clarity while limiting sound transmission to adjacent spaces

General

• Bluetooth wireless technology
• RF remote control
• Integrated table/wall mount; optional TV mount available
• Kensington security slot

• MeetUp ConferenceCam
• Remote control
• USB 2.0 cable: 5 m
• Power supply
• Wall mount and hardware
• User documentation
