Description

• Model number: TXB073
• Chipset: ASIX/AX99100
• Port number: 1 * Serial port
• Interface: PCI Express 1x slot
• Dimension: 65.3*58.2*16mm

Operating System Support

• Windows 10(32/64), 8/8.1 (32/64), 7(32/64), Vista(32/64), XP(32/64), 2000
• Windows Server 2012, 2008 R2, 2003(32/64)
• Mac OS 10.x (Intel-based, tested up to 10.9)
• Linux 2.4.x and newer (tested up to 3.5)

Environment

• Working temperature: 0℃-50℃
• Relative humidity: 10%-90% (non-condensing)
• Storage temperature: -0℃-80℃
• Relative humidity: 5%-90% (non-condensing)

Functions

Serial port:

• Supports RS232, RS485, and RS422 modes
• Bi-directional speeds from 50 bps to 16 Mbps/Port
• Full control of the serial modem
• Supports hardware and software flow control
• Supports 5, 6, 7, 8, and 9-bit serial format
• Custom baud rates supported with external clock or internal PLL programming
• On-chip 256-byte FIFO depth in transmit and receive path of each serial port
• Supports remote wake-up and power management features
• Support for disabling the serial port transceiver
• Supports slow IrDA on all IEEE1284 serial ports
• Four compatible UARTs compatible with 16C450/550/Extended 550/650/Enhanced mode
